Powerlynk Lynks 6kW Hybrid Inverter – Flexible, High-Efficiency Solar Power Solution

• The Powerlynk Lynks 6kW is a versatile hybrid inverter designed for users who want the performance and flexibility of Powerlynk technology without integrated battery storage. Ideal for residential and light commercial applications, this inverter works seamlessly with conventional PV systems and micro-inverters, making it a cost-effective and adaptable solution for a wide range of solar setups.
• With twin MPPT technology, high conversion efficiency, and full compatibility with Sunsynk low-voltage batteries, the Powerlynk Lynks 6kW delivers reliable power today while remaining future-ready for battery expansion.

Key Features & Benefits

• 6kW hybrid inverter for residential and small commercial use
• Compatible with standard PV arrays and micro-inverters
• Twin MPPT design maximizes solar energy harvest throughout the day
• Supports Li-ion and lead-acid batteries (48V systems)
• Fully compatible with Sunsynk low-voltage batteries for flexible storage options
• Optional Sunsynk Data Logger for smart monitoring and energy management
• High efficiency with advanced protection features
• Ideal where flexibility, value, and scalability are required

Battery Input Parameters

• Supported Battery Types: Lithium-Ion / Lead-Acid
• Nominal Battery Voltage: 48V
• Battery Voltage Range: 40–60V
• Max. Charge Voltage: ≤60V (configurable)
• Max. Charge Current: 100A (configurable)
• Max. Discharge Current: 130A (configurable)
• Recommended Battery Capacity: 100–2000Ah
• Li-Ion Charging: BMS communication supported

PV String Input Parameters

• Max. DC Input Power: 4000W × 2 (8,000W total)
• Max. DC Voltage: 500V
• MPPT Voltage Range: 120–450V
• Start-Up Voltage: 150V
• Max. Input Current: 15A × 2 MPPTs (30A total)

AC Output Parameters (Backup / Essential Load)

• Max. Output Power: 6000W
• Max. Apparent Power: 6000VA
• Peak Apparent Power: 12,000VA
• Max. Output Current: 26A
• Nominal Output Voltage: 220 / 230 / 240Vac (configurable)
• Nominal Frequency: 50 / 60Hz (±0.2%, configurable)
• Max. Bypass Current: 40A
• Transfer Time: 10ms
• THDv (Resistive Load): <3%

AC Input Parameters (On-Grid / Bypass Mode)

• Max. Input Power: 6000W
• Max. Output Power to Load: 6000W
• Max. Apparent Input/Output Power: 6000VA
• Nominal Voltage: 220 / 230 / 240Vac (auto-adjust)
• Nominal Frequency: 50 / 60Hz (auto-adjust)
• Max. Bypass Current: 40A
• Transfer Time: 10ms

Efficiency

• Maximum Efficiency: 97.6%
• Battery-to-Load Efficiency: 94.0%
• European Efficiency: 97.0%
• MPPT Efficiency: 99.9%

Integrated Protection Features

• Battery over-charge protection
• Battery low-voltage protection
• Over-temperature protection
• Output overload protection
• Output short-circuit protection

Ideal Applications

• Residential solar power systems
• Hybrid solar setups without built-in storage
• Grid-tied systems with future battery expansion plans
• Users seeking value, flexibility, and smart energy control
